| Brand Name: | SMX |
| Model Number: | MX-CL8200lumen |
| MOQ: | 1pc |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/Monthly |
Experience stunning visuals and exceptional image quality with our 8200-lumen laser projector featuring WUXGA resolution. This projector is designed for professional environments and combines high brightness, vibrant colors, and sharp detail to deliver outstanding performance across various applications.
Elevate your visual experiences with our 8200-lumen laser projector with WUXGA resolution, combining cutting-edge technology, reliability, and exceptional performance for diverse settings and applications.
| Model No. | MX-VL820U |
|---|---|
| Brightness (Lumen) | 8200 |
| Overall Spec | |
| Panel | Display Panel: 3x0.64" with MLA |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
| Light source Lifetime | Full Normal / ECO mode: 20000hrs |
| Projection Lens | F: 1.58-2.02 f: 15.3mm-24.6mm Zoom/Focus: Manual Throw Ratio: 1.08 (wide)-1.76 (tele) Zoom Ratio: 1.6 Screen size: 30-300 inch Lens Shift: V:＋45%～0%, H:±21% |
| CR | Contrast Ratio: 5000000:1 |
| Noise | Noise(dB): 39dB(Normal) / 31dB(ECO1)/ 29dB(ECO2) |
| Uniformity | Uniformity: 80% |
| AR | Aspect Ratio: Native:16:10 Compatible: 4:3/16:9 |
| Terminal (I/O port) | |
| Input | VGA: *1 HDMI 1.4B(IN): *2 USB-A: *1 USB-B: *1 (Display) RJ45: *1 (Display) HD BaseT: *1(Optional) Audio in: *1 |
| Output | VGA: *1 Audio out: *1 |
| Control | RS232: *1 RJ45: *1 (Control) USB-B: *1 (For upgrade) |
| General Spec | |
| Audio | Speaker: 16W*1 |
| Other Functions | |
| Keystone | Keystone Correction (Lens@center): V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction 4 Corner Correction Grid image tune |
| LAN Control | LAN Control-RoomView (Crestron): Yes LAN Control--AMX Discovery: Yes LAN Control--PJ Link: Yes |
| Display Resolution | Computer Signal Input: VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz Video Signal Input: 480i, 480p, 576i, 576p, 720p, 1080i and 1080p |
| SW setting | Auto Setup: INPUT SEARCH, AUTO PC, Auto Keystone Picture mode: Dynamic, Standard, Cinema, Colorboard, sim-DICOM, Blackboard(Green) Auto Ceiling: Yes |
| Others | 360° projection: Yes Edge Blending: Yes |
