| Brand Name: | SMX |
| Model Number: | MX-SL7500U |
| MOQ: | 1pc |
| Price: | 2680usd/pc |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/Monthly |
| Model No. | MX-SL7500U |
|---|---|
| Brightness (Lumen) | 7500 |
| Overall Spec | |
| Panel | Display Panel: 3x0.64" with MLA |
| Light source | NICHIA LASER |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
| Lifetime | Full Normal/Normal mode: 20000hrs |
| Projection Lens | |
| F | 1.7~1.8 |
| f | 9.66mm-11.65mm |
| Zoom/Focus | Manual |
| Throw Ratio | 0.68 (wide)-0.82 (tele) |
| Zoom Ratio | 1.21 |
| Screen size | 50-300inch |
| Lens Shift | V:＋50%～0%, H:±20% |
| CR | Contrast Ratio: 5000000:1 |
| Uniformity | Uniformity: 80% |
| AR | Aspect Ratio: Native:16:10, Compatible: 4:3/16:9 |
| Terminal (I/O port) | |
| Input |
VGA: *1 HDMI 1.4B(IN): *2 USB-A: *1 USB-B: *1 (Display) RJ45: *1(Display) HD BaseT: *1(Optional) Audio in (mini jack,3.5mm): *1 |
| Output |
VGA: *1 Audio out (mini-jack,3.5mm): *1 |
| Control |
RS232: *1 RJ45: *1 (Control) USB-B: *1 (For upgrade) |
| General Spec | |
| Audio | Speaker: 16W*1 |
| Other Functions | |
| Keystone |
Keystone Correction (Lens@center): V: ±15°, H: ±15° Pincushion/Barrel Correction 6 Corner Geometry correction 4 Corner Correction Grid image tune |
| Others |
360° projection: Yes Edge Blending: Yes |
| Accessory | |
| Manual Languages | Chinese, English |
| Standard Accessories | Power cord, HDMI cable, Remote control |
