| Brand Name: | SMX |
| Model Number: | MX-SL6000U |
| MOQ: | 1 |
| Price: | 2080usd/pc |
| Payment Terms: | T/T |
| Supply Ability: | 100000pcs/monthly |
| Model | MX-SL6000U | |
|---|---|---|
| Brightness | 6000 Lumens | |
| Display | Panel | 3x0.64" with MLA |
| Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Aspect Ratio | Native:16:10, Compatible: 4:3/16:9 | |
| Light Source | Normal Mode | 20,000 hours |
| ECO1 Mode | 30,000 hours | |
| ECO2 Mode | 30,000 hours | |
| Lens | Vendor | RICOH |
| F | F1.6 | |
| f | 6.39mm | |
| Zoom/Focus | Manual | |
| Throw Ratio | 0.44:1 | |
| Screen Size | 55-300 inch | |
| Contrast Ratio (FOFO) | 5,000,000:1 | |
| Noise Level | 37dB (Normal), 27dB (ECO) | |
| Uniformity (Actual Min - JISX6911) | 80% | |
| Input Ports | VGA | 1 |
| HDMI 1.4B(IN) | 2 | |
| USB-A | 1 | |
| USB-B | 1 (Display) | |
| RJ45 | 1 (Display) | |
| Audio In (3.5mm) | 1 | |
| RS232 | 1 | |
| Output Ports | VGA | 1 |
| Audio Out (3.5mm) | 1 | |
| Control | RJ45 | 1 (Control) |
| USB-B | 1 (For upgrade) | |
| LAN Control | RoomView (Crestron), AMX Discovery, PJ Link | |
| General | Speaker | 16W*1 |
| Dust Filter | Included (8000h life) | |
| Power | Requirements | 100~240V@ 50/60Hz |
| Normal Mode | 360W (Max) | |
| ECO1 Mode | 280W (Max) | |
| ECO2 Mode | 230W (Max) | |
| Standby | <0.5W | |
| Cooling Time | 0s, Normal, 30s | |
| Environment | Operating Temp | 0 to 40°C |
| Operating Humidity | 20-80% | |
| Storage Temp | -10 to 50°C | |
| High Altitude | 0~3000m | |
| Dimensions (W×D×H) | 405 × 404 × 164 mm | |
| Net Weight | 8.1 kg | |
| Accessories | Power cord, Remote control, HDMI Cable | |
| Manual Languages | Chinese, English | |
