| Brand Name: | SMX |
| Model Number: | MX-WPL500U |
| MOQ: | 1pc |
| Price: | 1980usd/pc |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/Monthly |
| Model No. | MX-WPL500U |
|---|---|
| Brightness | |
| Lumen | 5000 |
| Overall Spec | |
| Panel | Display Panel | 3x0.63" with MLA |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA(1920x1200) |
| Light source | |
| Lifetime | Normal mode | 20000hrs ECO2 mode | 30000hrs |
| Projection Lens | |
| F | F1.7 |
| f | 2.94mm |
| Lens Vendor | RICOH |
| Zoom/Focus | Manual |
| Throw Ratio | 0.235:1 |
| Screen size | 80-120" |
| CR | Contrast Ratio | 5000000:1 |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9 |
| Terminal(I/O port) | |
| Input | VGA*1,HDMI*2,USB-A*,USB-B*1(Display),RJ45*1(Display), Audio in*1 |
| Output | VGA*1 ,Audio out*1 |
| Control | RS232*1,RJ45*1,USB-B *1 |
| General Spec | |
| Audio | Speaker | 16W*1 |
| Other Functions | |
| Keystone | Keystone Correction (Lens@center) | V: ±5° H:±5° Pincushion/Barrel Correction 6 Corner Geometry correction Grid image tune |
| LAN Control | LAN Control-RoomView (Crestron) | Yes LAN Control-- AMX Discovery | Yes LAN Control-- PJ Link | Yes |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i and 1080p |
| Others | 360° projection | Yes |
| Dimension&Weight | |
| Product Size (WxHxD mm) | 520x435x168 |
| Net. Weight (KG) | 11 |
| Accessory | |
| Manual Languages | Chinese, English |
| Standard Accessories | Power cord, Remote control |
