| Brand Name: | SMX |
| Model Number: | MX-WPL500U |
| MOQ: | 1pc |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/Monthly |
| Model No. | MX-WPL500U |
|---|---|
| Lumen | 5000 |
| Resolution | WUXGA |
| Light source | Laser |
| Panel | Display Panel: 3x0.64" with MLA Display Technology: Liquid Crystal Display Native Resolution: WUXGA (1920 x 1200) |
|---|---|
| Light Source Lifetime | Normal mode: 20000hrs ECO mode: ≥20000hrs ECO2 mode: 30000hrs |
| Projection Lens | F: F1.7 f: 2.94mm Lens Vendor: RICOH Zoom/Focus: Manual Throw Ratio: 0.235:1 Screen size: 80-150 |
| CR | Contrast Ratio: 5000000:1 |
| Noise | Noise(dB): 37dB(Normal) 30dB(ECO1) 27dB(ECO2) |
| Uniformity | Uniformity(Actual Min)-JISX6911: 80% |
| AR | Aspect Ratio: Native:16:10 Compatible: 4:3/16:9 |
| Input | VGA: *1 HDMI 1.4B(IN): *2 USB-A: *1 USB-B: *1(Display) RJ45: *1(Display) Audio in (mini jack,3.5mm): *1 |
|---|---|
| Output | VGA: *1 Audio out (mini-jack,3.5mm): *1 |
| Control | RS232: *1 RJ45: *1 (Control) USB-B: *1 (For upgrade) |
| Audio | Speaker: 16W*1 |
|---|---|
| Keystone | Keystone Correction (Lens@center): V: ±5° H:±5° Pincushion/Barrel Correction 6 Corner Geometry correction Grid image tune |
| LAN Control | LAN Control-RoomView (Crestron): Yes LAN Control--AMX Discovery: Yes LAN Control--PJ Link: Yes |
| Others | 360° projection: Yes |
| Product Size (WxHxD mm) | 520x435x168 |
|---|---|
| Net. Weight (KG) | 11 |
| Packaging (WxHxD mm) | 610*526*266 |
| Gross. Weight (KG) | 13.5 |
| Manual Languages | Chinese, English |
|---|---|
| Standard Accessaries | Power cord, Remote control, HDMI Cable |
