| Brand Name: | SMX |
| Model Number: | MX-X12000U |
| MOQ: | 1pc |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/Monthly |
| Model No. | MX-X12000U |
|---|---|
| Brightness (ANSI Lumens) | 12000 lumen |
| Light source | Laser |
| Display Panel | 3x0.76" |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
| Light source Lifetime | Normal mode: 20000hrs ECO mode: 20000hrs |
| Projection Lens |
Zoom Lens Manual(Standard Len) Throw Ratio(16:10): 1.46-2.95 Zoom Ratio: 2 Lens Shift V: +50%,-10% Lens Shift H: ±20% |
| Contrast Ratio(Min) | 3,000,000:1 |
| Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal |
| Input/Output Ports |
VGA: *1 HDMI 1.4(IN): *2 USB-A: *1 (5V/1.5A) USB-B: *1 (Display) RJ45: *1 (Display) DVI-D: *1 HD BaseT: *1 HD-SDI(3G-SDI): Optional Audio in (mini jack,3.5mm): *1 Audio out (mini-jack,3.5mm): *1 |
| Control |
RS232: *1 RJ45: *1 (Control) USB-B: *1 (For upgrade) Wired Remote(IN): *1 Wired Remote(OUT): *1 |
| Other Functions |
360° Omni bearing installation Edge Blending: Yes Keystone Correction: V: ±30°, H: ±30° LAN Control: RoomView (Crestron), AMX Discovery, PJ Link |
| Dimensions & Weight |
MAX Dimensions (WxHxD mm): 600*218*503 Net. Weight: ~25kg |
| Accessories |
Power cord(3m,Black), Remote, HDMI Cable Manual Languages: Chinese, English |
