| Brand Name: | SMX |
| Model Number: | MX-X20000U |
| MOQ: | 1pc |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 12000pcs/Monthly |
| Model# | MX-EG05ZLM | MX-EG06ZLM | MX-EG08ZLM | MX-EG12ZLM | MX-EG20ZL | OL-EG39ZLM |
|---|---|---|---|---|---|---|
| Image circle | Φ34.6 | Φ35.5 | Φ37.9 | Φ37.9 | Φ37.9 | Φ37.9 |
| Zoom/Focus | Motorized | Motorized | Motorized | Motorized | Motorized | Motorized |
| F# (Wide-Tele) | 1.85-2.20 | 1.84-2.25 | 1.80-2.24 | 1.80-2.24 | 1.84-2.58 | 1.85-2.42(TBD) |
| f(mm) | 12.0-14.6 | 14.4-19.1 | 19.0-27.6 | 27.7-44.3 | 43.8-86.0 | 86.8-163.5(TBD) |
| Throw Ratio (16:10) | 0.53-0.65 | 0.65-0.87 | 0.86-1.25 | 1.24-2.01 | 1.98-3.95 | 3.95-7.50(TBD) |
| Zoom Ratio | 1.23 | 1.34 | 1.45 | 1.62 | 1.99 | 1.90(TBD) |
| Lens shift H | ±20% | ±20% | ±25% | ±25% | ±25% | ±25% |
| Lens shift V | ±50% | ±55% | ±65% | ±65% | ±65% | ±65% |
| Screen Size | 60-500inch | 60-500inch | 60-500inch | 60-500inch | 60-500inch | 60-500inch |
| Model# | MX-X20000U | |
| Brightness | Brightness(Lumen) | 20,000 |
| Overall Spec | ||
| Panel | Display Panel | 3x1.0" |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Laser Lifetime | ||
| Normal mode | 20000hrs | |
| ECO mode | 30000hrs | |
| Projection Lens (STD) | ||
| Len Model | [MX-EG12ZLM](#Lens!A1) | |
| Zoom/Focus | Motorized | |
| Throw Ratio (16:10) | 1.24-2.01 @100inch | |
| F | 1.8-2.24 | |
| f | 27.7-44.3mm | |
| Zoom Ratio | 1.62 | |
| Screen size | 60-500 inch | |
| Lens Shift V | ±65% | |
| Lens Shift H | ±25% | |
| CR | ||
| Contrast Ratio(Min) | 3,000,000:1 | |
| Noise | ||
| Noise(dB) | Full:46db / Normal:44db / Eco1:43db / Eco2:42db | |
| Uniformity | ||
| Uniformity | TYP:90% | |
| AR | ||
| Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal/16:6 |
|
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1 (Display) | |
| RJ45 | *1 (Display) | |
| DVI-D | *1 | |
| HD BaseT | *1 | |
| Audio in(mini jack,3.5mm) | *1 (VGA/DVI-D share) | |
| DMX512 | *1 | |
| Output | HDMI 1.4(OUT) | *1 |
| Audio out (mini-jack,3.5mm) | *1 | |
| Control | RS232C (Input) | *1 |
| RS232C (Output) | *1 | |
| Wired Remote(IN) | *1 | |
| Wired Remote(OUT) | *1 | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30° H:±30° |
| Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction |
||
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Others | 360° projection | 360° Install |
| Edge Blending | Yes | |
| Adjustable brightness | Yes | |
| Dimension&Weight | ||
| Product Size (WxHxD mm) | 599X240.2X493.8mm (not including lens) | |
| Net. Weight (KG) | 28.9Kg (not including lens) | |
| Accessory | ||
| Manual Languages | Chinese, English | |
| Standard Accessories | Power cord (3m, Black), Remote control | |
