| Brand Name: | SMX |
| Model Number: | MX-X20000U |
| MOQ: | 1 |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 100000pcs/monthly |
| Model# | MX-X20000U |
| Brightness(Lumen) | 20,000 |
| Overall Specifications | |
| Display Panel | 3x1.0" |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
| Laser Lifetime (Normal mode) | 20000hrs |
| Laser Lifetime (ECO mode) | 30000hrs |
| Projection Lens (STD) | |
| Lens Model | MX-EG12ZLM |
| Zoom/Focus | Motorized |
| Throw Ratio (16:10) | 1.24-2.01 @100inch |
| F | 1.8-2.24 |
| f | 27.7-44.3mm |
| Zoom Ratio | 1.62 |
| Screen size | 60-500 inch |
| Lens Shift V | ±65% |
| Lens Shift H | ±25% |
| Contrast Ratio(Min) | 3,000,000:1 |
| Noise(dB) | Full:46db / Normal:44db / Eco1:43db / Eco2:42db |
| Uniformity | TYP:90% |
| Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal/16:6 |
| Model# | MX-EG05ZLM | MX-EG06ZLM | MX-EG08ZLM | MX-EG12ZLM | MX-EG20ZL | OL-EG39ZLM |
|---|---|---|---|---|---|---|
| Image circle | Φ34.6 | Φ35.5 | Φ37.9 | Φ37.9 | Φ37.9 | Φ37.9 |
| Lens Type | Zoom Lens ST3 | Zoom Lens ST2 | Zoom Lens ST1 | Zoom Lens STD | Zoom Lens L1 | Zoom Lens L2 |
| Zoom/Focus | Motorized | Motorized | Motorized | Motorized | Motorized | Motorized |
| F#(Wide-Tele) | 1.85-2.20 | 1.84-2.25 | 1.80-2.24 | 1.80-2.24 | 1.84-2.58 | 1.85-2.42(TBD) |
| f(mm) | 12.0-14.6 | 14.4-19.1 | 19.0-27.6 | 27.7-44.3 | 43.8-86.0 | 86.8-163.5(TBD) |
| Throw ratio(16:10) | 0.53-0.65 | 0.65-0.87 | 0.86-1.25 | 1.24-2.01 | 1.98-3.95 | 3.95-7.50(TBD) |
| Zoom Ratio | 1.23 | 1.34 | 1.45 | 1.62 | 1.99 | 1.90(TBD) |
| Lens shift H | ±20% | ±20% | ±25% | ±25% | ±25% | ±25% |
| Lens shift V | ±50% | ±55% | ±65% | ±65% | ±65% | ±65% |
| Screen Size | 60-500inch | 60-500inch | 60-500inch | 60-500inch | 60-500inch | 60-500inch |
