| Brand Name: | SMX |
| Model Number: | MX-X20000U |
| MOQ: | 1pc |
| Price: | 21500usd/pc |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/Monthly |
| Model# | MX-X20000U |
|---|---|
| Brightness | |
| Brightness(Lumen) | 20,000 |
| Overall Spec | |
| Panel | Display Panel |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
| Laser Lifetime | Normal mode: 20000hrs ECO mode: 30000hrs |
| Projection Lens | |
| Len Model | MX-EG12ZLM |
| Zoom/Focus | Motorized |
| Throw Ratio (16:10) | 1.24-2.01 @100inch |
| F | 1.8-2.24 |
| f | 27.7-44.3mm |
| Zoom Ratio | 1.62 |
| Screen size | 60-500 inch |
| Lens Shift V | ±65% |
| Lens Shift H | ±25% |
| CR | Contrast Ratio(Min): 3,000,000:1 |
| Noise | Noise(dB): Full:46db / Normal:44db / Eco1:43db / Eco2:42db |
| Uniformity | Uniformity: TYP:90% |
| AR | Aspect Ratio: Native:16:10 Compatible: 4:3/16:9/normal/16:6 |
| Terminal(I/O port) | |
| Input |
VGA: *1 HDMI 1.4(IN): *2 USB-A: *1 USB-B: *1 (Display) RJ45: *1 (Display) DVI-D: *1 HD BaseT: *1 Audio in(mini jack,3.5mm): *1 (VGA/DVI-D share) DMX512: *1 |
| Output |
HDMI 1.4(OUT): *1 Audio out (mini-jack,3.5mm): *1 |
| Control |
RS232C (Input): *1 RS232C (Output): *1 Wired Remote(IN): *1 Wired Remote(OUT): *1 |
| Other Functions | |
| Keystone |
Keystone Correction: V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction |
| OSD |
Languages: 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Farsi |
| LAN Control |
LAN Control-RoomView (Crestron): Yes LAN Control-AMX Discovery: Yes LAN Control-PJ Link: Yes |
| Display Resolution | Computer Signal Input: VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Others |
360° projection: 360° Install Edge Blending: Yes Adjustable brightness: Yes |
| Dimension&Weight | |
| Product Size (WxHxD mm) | 599X240.2X493.8mm (not including lens) |
| Net. Weight (KG) | 28.9Kg (not including lens) |
| Accessory | |
| Manual Languages | Chinese, English |
| Standard Accessories | Power cord (3m, Black), Remote control |
