| Brand Name: | SMX |
| Model Number: | MX-12000U |
| MOQ: | 1Pc |
| Payment Terms: | T/T |
| Supply Ability: | 15000pcs/monthly |
Designed for demanding professional AV applications, this 12,000 ANSI lumens 3LCD laser projector combines high brightness, native WUXGA 1920×1200 resolution, interchangeable lens flexibility, and advanced installation features.
With edge blending, lens shift, geometry correction and 360° installation, it is an ideal projection solution for auditoriums, conference halls, museums, exhibitions, churches, rental events, stages and projection mapping projects.
12,000 ANSI Lumens | 3LCD | WUXGA | 20,000H Laser | Edge Blending | Interchangeable Lens
With up to 12,000 ANSI lumens brightness, the projector delivers bright, clear, and highly visible images on large projection surfaces.
It is designed for professional environments where high brightness is essential, including auditoriums, conference halls, event venues, and exhibition spaces.
12,000 ANSI Lumens
Clear images on large screens
Strong visual performance in ambient light
Suitable for professional large-venue installations
Designed for continuous commercial use
Advanced 3LCD display technology provides excellent color reproduction and balanced brightness, delivering vivid images with natural color transitions.
Whether displaying presentations, videos, digital artwork, or immersive content, the projector provides consistent image quality for professional visual applications.
3LCD Display Technology
Rich and natural colors
Smooth color gradation
Excellent image consistency
Suitable for business and creative visual content
Native WUXGA 1920×1200 resolution provides sharp text, detailed graphics and high-quality video reproduction.
The native 16:10 aspect ratio offers additional vertical display space compared with traditional 16:9 formats, making it especially suitable for presentations, visualization systems and professional AV installations.
Native Resolution: WUXGA 1920×1200
Aspect Ratio: 16:10
The solid-state laser light source provides up to 20,000 hours of operation, significantly reducing the need for frequent lamp replacement.
It is ideal for fixed installations and professional projects requiring reliable long-term operation.
Up to 20,000 hours of laser life
Reduced maintenance requirements
Stable long-term brightness
Fast startup
Designed for professional installation
The closed internal circulation cooling design also helps improve long-term operating reliability.
One of the major advantages of this projector is its flexible interchangeable lens system.
Six optional lenses provide a total throw ratio range from approximately:
This allows the same projector platform to be adapted to different room sizes, screen dimensions, and installation distances.
Projection Screen Size: approximately 40–500 inches
This wide lens selection makes the projector suitable for everything from compact rear installations to very large auditoriums and long-distance projection systems.
Professional AV projects often involve restricted installation positions, unusual projection angles, or irregular projection surfaces.
This projector provides multiple installation adjustment functions to simplify setup.
6-Corner Correction
Pincushion Correction
Barrel Correction
Grid ImageTune
Image geometry adjustment
These functions help installers achieve accurate image positioning without relying entirely on the physical position of the projector.
The projector supports 360-degree installation, allowing it to operate in a wide range of orientations.
This makes it particularly suitable for:
Ceiling installation
Portrait-style installation
Vertical projection
Floor projection
Museum installations
Stage installations
Projection mapping projects
Immersive environments
Integrated edge blending capability allows multiple projectors to work together to create a larger continuous image.
This is especially useful when a single projector cannot cover the required projection area.
Panoramic projection
Immersive rooms
Projection mapping
Museums
Digital exhibitions
Simulation systems
Large-format displays
Multi-projector installations
Combined with geometry correction, the projector provides greater flexibility for complex multi-channel projection systems.
High brightness, interchangeable lenses, geometry correction and edge blending make this projector well suited for professional projection mapping applications.
It can be used to project creative visual content onto buildings, exhibition walls, stages and irregular surfaces.
Typical projects include:
Architectural Mapping | Museum Exhibitions | Immersive Art | Stage Shows | Theme Parks | Brand Events
A comprehensive range of interfaces allows the projector to integrate with modern AV equipment, control systems, and signal distribution networks.
3G-SDI can be configured as an optional interface where required.
HDBaseT support is particularly useful for professional installations where video and control signals need to be transmitted over longer distances.
12,000 ANSI lumens provides the brightness required for large screens and larger audiences.
WUXGA resolution ensures clear presentations, text, and business graphics.
Suitable for large sanctuary screens, presentations, live video, and worship content.
Edge blending and geometry correction support immersive displays and digital exhibitions.
Flexible lenses, high brightness and geometry adjustment make the projector suitable for architectural and creative mapping.
Professional brightness and flexible installation support temporary events, stages, and live productions.
Suitable for large lecture theaters and educational environments requiring high brightness and clear text.
| Model | ||
| Model | MX-X12000U | |
| Brightness( Ansi Lumens ) | 12000lumen | |
| Resolution | WUXGA (1920 x 1200) | |
| Light source | Laser | |
| Overall Spec | ||
| Panel | Display Panel | 3x0.76" |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Light source Life time |
Normal mode | 20000hrs |
| ECO mode | 20000hrs | |
| Projection Lens | Len Type | Zoom Lens |
| Zoom/Focus | Manual | |
| Throw Ratio(16:10) | 1.46-2.95 | |
| F#(Wide-Tele) | F1.7~2.37 | |
| f(mm) | 24.4-48.6 | |
| Zoom Ratio | 2 | |
| Screen size | 40-500 inch | |
| Weight | Approx. 0.8 kg | |
| Lens Shift V | +50%,-10% | |
| Lens Shift H | ±20% | |
| CR | Contrast Ratio(Min) | 100000:1 |
| Noise | Noise(dB) | Normal(90%): 35dB ECO1(75% ): 32dB ECO2(45% ): 32dB |
| Uniformity | Uniformity | 80% |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4(IN) | *2 | |
| USB-A | *1(5V/1.5A) | |
| USB-B | *1(Display) | |
| RJ45 | *1(Display) | |
| DVI-D | *1 | |
| HD BaseT | *1 | |
| HD-SDI(3G-SDI) | Optional | |
| Audio in (mini jack,3.5mm) |
*1 (VGA/DVI-D share) | |
| Output | VGA | *1 |
| HDMI 1.4(OUT) | *1 | |
| Audio out (mini-jack,3.5mm) |
*1 | |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) | |
| USB-B | *1 (For upgrade) | |
| Wired Remote(IN) | *1 | |
| Wired Remote(OUT) | *1 | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30°; H: ±30° Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction |
| LAN Control | LAN Control-RoomView (Crestron) |
Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Others | 360° projection | 360° omnibearing installation |
| Edge Blending | Yes | |
Rather than focusing only on brightness, this projector provides a complete platform for professional AV installations.
Powerful brightness for large screens and demanding venues.
Vivid and natural color reproduction.
Sharp 1920×1200 image quality.
Throw ratios from 0.60:1 to 7.02:1.
Designed for multi-projector and panoramic installations.
Ideal for irregular projection surfaces.
Greater installation freedom.
HDMI, HDBaseT, LAN, RS-232C and more.
Long service life with reduced maintenance.
We provide OEM and ODM support for distributors, AV integrators, rental companies, and project contractors.
Available services can include:
OEM branding
Logo customization
Packaging customization
Product configuration support
Lens selection assistance
Projection distance calculation
Multi-projector solution design
Edge blending project support
Technical consultation
Project-based product recommendations
For larger installations, our team can assist in selecting the appropriate projector, lens, and installation configuration based on screen size, throw distance, and application environment.
It is designed for professional large-venue applications including auditoriums, conference halls, museums, churches, stages, exhibitions, projection mapping and rental events.
Yes. Six lens options are available, covering throw ratios from approximately 0.60:1 to 7.02:1.
Yes. High brightness, edge blending, geometry correction, and multiple lens options make it suitable for professional projection mapping projects.
Yes. Edge blending is available for multi-projector panoramic and immersive projection systems.
Yes. It supports 360° installation, offering greater flexibility for creative and complex installations.
Yes. HDBaseT is available for long-distance professional AV signal transmission.
The laser light source is rated for up to approximately 20,000 hours, depending on operating conditions and settings.
Yes. OEM/ODM services and project solution support are available for distributors, integrators, and professional AV customers.
Whether you are planning an auditorium, conference hall, immersive exhibition, projection mapping installation, or large-scale event, this 12,000 ANSI lumens 3LCD laser projector provides the brightness, image quality, and installation flexibility required for professional projects.
Send us your screen size, projection distance, and application environment. Our team can recommend a suitable projector and lens solution for your project.
