| Brand Name: | SMX |
| Model Number: | MX-12000U |
| MOQ: | 1Pc |
| Payment Terms: | T/T |
| Supply Ability: | 15000pcs/monthly |
Designed for professional AV applications, this 12,000 ANSI lumens 3LCD laser projector delivers high brightness, WUXGA resolution, and flexible installation for large venues, projection mapping, museums, stages, and conference halls.
12,000 ANSI Lumens | 3LCD | WUXGA | 20,000H Laser | Edge Blending | Interchangeable Lens
Powerful 12,000 ANSI lumens output provides clear and vivid images on large screens, making the projector ideal for professional indoor venues and large-scale visual applications.
Equipped with 3LCD display technology and native WUXGA 1920*1200 resolution, the projector delivers vivid colors, sharp details, and smooth image performance.
The laser light source offers up to 20,000 hours of operation, providing stable performance with lower maintenance requirements for professional installations.
Six optional lenses provide flexible installation for different projection distances.
Designed for complex professional projects, the projector supports flexible positioning and image adjustment.
Additional functions include:
Built-in edge blending and geometry correction make this projector suitable for multi-projector and immersive visual systems.
A wide range of professional interfaces makes integration with AV systems simple and flexible.
| Model | MX-X12000U |
|---|---|
| Brightness (ANSI Lumens) | 12000 lumen |
| Resolution | WUXGA (1920 x 1200) |
| Light Source | Laser |
| Display Panel | 3x0.76" |
| Display Technology | Liquid Crystal Display |
| Laser Lifetime | 20,000 hours (Normal & ECO mode) |
| Throw Ratio (16:10) | 1.46-2.95 |
| Zoom Ratio | 2 |
| Screen Size | 40-500 inch |
| Contrast Ratio | 100,000:1 |
| Noise Level | Normal (90%): 35dB, ECO1 (75%): 32dB, ECO2 (45%): 32dB |
Rather than focusing only on brightness, this projector provides a complete platform for professional AV installations.
Professional Support for Global AV Partners
We provide OEM and ODM support for distributors, AV integrators, rental companies, and project contractors.
Available services can include:
For larger installations, our team can assist in selecting the appropriate projector, lens, and installation configuration based on screen size, throw distance, and application environment.
What type of applications is this projector suitable for?
It is designed for professional large-venue applications including auditoriums, conference halls, museums, churches, stages, exhibitions, projection mapping, and rental events.
Does the projector support interchangeable lenses?
Yes. Six lens options are available, covering throw ratios from approximately 0.60:1 to 7.02:1.
Can it be used for projection mapping?
Yes. High brightness, edge blending, geometry correction, and multiple lens options make it suitable for professional projection mapping projects.
Does it support edge blending?
Yes. Edge blending is available for multi-projector panoramic and immersive projection systems.
Can the projector be installed vertically or at different angles?
Yes. It supports 360° installation, offering greater flexibility for creative and complex installations.
Does it support HDBaseT?
Yes. HDBaseT is available for long-distance professional AV signal transmission.
What is the laser light source life?
The laser light source is rated for up to approximately 20,000 hours, depending on operating conditions and settings.
Do you provide OEM and ODM services?
Yes. OEM/ODM services and project solution support are available for distributors, integrators, and professional AV customers.
The 12,000 ANSI lumens 3LCD laser projector combines high brightness, flexible lens options, edge blending, and professional installation features for demanding commercial projects.
Need help choosing the right lens?
Send us your:
Screen Size + Projection Distance + Application
We can recommend the suitable projector and lens configuration for your project.
